CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable
Detail produk:
Tempat asal: | Shenzhen, Cina |
Nama merek: | Neutral/OEM/Takfly |
Sertifikasi: | CE/ROHS/REACH/CPR/ISO9001/ISO14001 |
Nomor model: | Kabel Patch MPO |
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: | 1 |
---|---|
Harga: | Negotiable |
Kemasan rincian: | tas PE |
Waktu pengiriman: | 3-7 hari kerja |
Syarat-syarat pembayaran: | Western Union, L/C, T/T, Paypal |
Menyediakan kemampuan: | 100 PCS/hari |
Informasi Detail |
|||
inti: | 24 core | Jenis serat:: | SM dan MM |
---|---|---|---|
Panjang: | 1m, 3m, 5m dan Disesuaikan. | Diameter kabel:: | 3.0mm, 4.5mm |
Jenis konektor: | MPO | jaket kabel: | LSZH |
Warna Kabel: | Kuning, Aqua, Violet, Hijau Limau | Aplikasi: | Pusat Data |
Nama Produk: | Kabel Patch MPO Serat Optik | Cara Fanout Lainnya: | MTP, LC tersedia |
Deskripsi Produk
Fiber Optic MPO 24 Cores Patch Cord Data Center MPO-MPO Fiber Cable
Fiber Optic MPO Patch Cord Name:
Fiber Optic 24 Cores MPO-MPO Patch Cord
Fiber Optic MPO Patch Cord Description:
This MPO-MPO Patch Cord is for the 24 Cores, and can do it for SM and MM according to the requirements. Other cores like 8 cores, 12 cores also available.
This type cable diameter is commonly for 3.0mm, and 4.5mm diameter is also available. The MPO patch cord is with very high density, which is widely used in the Data Center with high performance.
Fiber Optic MPO Patch Cord Features:
Precision molded MT ferrule |
High precision guide pins for exact alignment |
Compact design, up to 4,8,12,24 fibers |
IEC 61754-7 Compliant |
Cable diameter 3.0mm, and 4.5mm available |
Fiber Optic MPO Patch Cord Applications:
- Telecommunication Networks
- Active Deviced/Transceiver Interface
- Gigabit Ethernet
- CATV, Video and Multimedia
- Premise Installations
- Optical Switch interframe connections
- Data Center
Fiber Optic MPO Patch Cord Specifications:
Item | LC,SC,ST,FC....... | MPO/MTP | |
End face type | PC,UPC and APC | PC and APC | |
Fiber type | SM(G652,G655,G657);MM(OM1-OM5) | ||
Core number | 12, 24 | ||
Cable Diameter | 0.9,2.0,3.0 | Mini Round cable:Max4.5mm; Ribbon cable:Max3.0*5.0mm | |
Insertion loss(dB) | ≤ 0.3 | Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max) | |
Return loss(Min) |
UPC SM:40dB APC SM:60 dB PC MM:25 dB |
SM: APC:60dB | MM: PC:20dB |
Test Wavelength (nm) | SM:1310/1550 MM:850/1300 | ||
Repeatability | ≤ 0.1dB | ||
Durability | ≤ 0.2dB | ||
Interchangeability | ≤ 0.2dB |
Why choose TAKFLY--Advantages as follows:
Professional manufacturer:
- With more than 21 years manufacturing experience in Fiber optic products;
- More than 450 assembly workers with 3 years experienced;
- More than 10 R&D Engineers;
- 16 Sets Germany imported Injection Machine and 16 Production Lines;
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
- OEM Brand is acceptable.
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.
Quality Control:
- Spot check the raw material incoming inspection before production;
- Fully check after every individual process finished;
- Fully check production half done;
- Fully check the finished products before packing;
- Spot check before shipping;
Delivery:
- Samples: 1-3 working days.
- Mass Production Order: 3-7 working days.
- Packaging: Plastic Bag, Carton and Pallet are available according to your request.
Price: If your QTY is big, the price could be negotiated.
